All three Chery Super Hybrid (CSH) plug-in hybrids charge through a Type 2 inlet and accept a maximum of 6.6kW AC. The Tiggo 7 and Tiggo 8 share an 18.4kWh battery and fill in about 2.8 hours; the Tiggo 9 carries a much larger 34.46kWh pack, taking around 5.2 hours. A 7.4kW single-phase smart wall charger is the right match for all three.
Home charge time
10–100% at 6.6kW
| Charging fact | Tiggo 7 & Tiggo 8 CSH | Tiggo 9 CSH |
|---|---|---|
| AC connection | Type 2 | |
| Maximum AC rate | 6.6kW single-phase | |
| Battery | 18.4kWh LFP | 34.46kWh |
| Best option for most homes | 7.4kW single-phase wall charger | |
| Public DC connection | CCS2 — up to 40kW | CCS2 — up to 71kW |
| V2L | Yes — up to 3.3kW, adapter required | |
Best for every Tiggo CSH
A single-phase 7.4kW (32A) charger supplies more than the car can take, so every Tiggo CSH charges at its full 6.6kW: about 2.8 hours for the Tiggo 7 and 8, or 5.2 hours for the Tiggo 9’s larger pack.
Load monitoring prevents overloading your mains while charging. Solar diversion varies charging power to match your solar generation — a strong match for a PHEV, since a modest solar array can cover most of a Tiggo 7 or 8 charge. Scheduling via the free app makes the most of off-peak rates.
About Chery Super Hybrid
Chery Super Hybrid (CSH) pairs a turbo-petrol engine with an electric drive system and a large plug-in battery. The Tiggo 7 (five-seat medium SUV) and Tiggo 8 (seven-seat large SUV) use the same 18.4kWh powertrain, while the flagship Tiggo 9 adds all-wheel drive and nearly double the battery.
For home charging they behave identically: Type 2, 6.6kW maximum AC. What changes is how long a full charge takes, and how quickly each will accept DC on the road.
| Item | Tiggo 7 Super Hybrid | Tiggo 8 Super Hybrid | Tiggo 9 Super Hybrid |
|---|---|---|---|
| Body | 5-seat medium SUV | 7-seat large SUV | 7-seat large SUV |
| Battery size | 18.4kWh LFP | 18.4kWh LFP | 34.46kWh |
| Electric-only range | ~90km (WLTP) / 93km (NEDC) | ~90km (WLTP) / 93km (NEDC) | ~146km (WLTP) / 170km (NEDC) |
| Drive | FWD | FWD | AWD |
| AC charge port | Type 2 | ||
| Maximum AC charge speed | 6.6kW single-phase | ||
| DC charge port | CCS2 | ||
| Maximum DC charge speed | Up to 40kW | Up to 40kW | Up to 71kW |
| DC fast charge 30–80% | ~20 min | ~20 min | ~18–20 min |
| V2L | Yes — up to 3.3kW, adapter required | ||
Charge times from 10% to 100%. The last few percent slow down as the cells balance, so these are estimates.
| Charger type | Charging power | Tiggo 7 & 8 (18.4kWh) | Tiggo 9 (34.46kWh) |
|---|---|---|---|
| Portable charger, standard NZ socket (8A) | 1.8kW | ~10.0 hrs | ~18.7 hrs |
| 10A portable Type 2 charger | 2.3kW | ~8.0 hrs | ~15.0 hrs |
| 16A portable charger (caravan plug) | 3.7kW | ~5.0 hrs | ~9.4 hrs |
| 32A single-phase wall charger | 6.6kW (vehicle limit) | ~2.8 hrs | ~5.2 hrs |
Estimates allow for approximately 10% charging losses. Actual speed can vary with temperature, battery condition and the vehicle’s charging behaviour near 100%.
Kilometres of electric driving added per hour of charging, based on WLTP range. Because these are plug-in hybrids, this is the number that matters most — every kilometre you add is a kilometre you don’t buy petrol for.
| Charger | Tiggo 7 & 8 | Tiggo 9 |
|---|---|---|
| 8A portable charger (standard socket) | ~8km per hour | ~7km per hour |
| 10A portable charger | ~10km per hour | ~9km per hour |
| 16A portable charger (caravan socket) | ~16km per hour | ~14km per hour |
| 7.4kW wall charger (6.6kW to the car) | ~29km per hour | ~25km per hour |
Want exact numbers for your power price and starting charge? Use the calculator below, or see our charge time calculator and charge cost calculator.
A portable Type 2 charger works well on a battery this size. A 10A unit plugs into a standard household socket and fills a Tiggo 7 or 8 overnight in around 8 hours. On the Tiggo 9’s larger pack it takes about 15 hours, so a wall charger makes more sense there.
Any portable charger for a Tiggo CSH must have a Type 2 vehicle connector.
Plug in EV chargers
Plug in EV chargers
Vehicle-side plug: Type 2. You’ll need your own Type 2 to Type 2 cable for public AC chargers and for any untethered (socket-only) wall charger. We recommend 5m.
Because the car caps at 6.6kW, a single-phase cable is sufficient. A 22kW three-phase cable also works and is worth considering only if you may later own a car that charges faster.
DC fast chargers have their cables attached, so nothing extra is needed there.
Charging Cables
Power anywhere
The Tiggo Super Hybrid range supports Vehicle-to-Load at up to 3.3kW through a plug-in adapter that gives you a standard New Zealand socket — enough for a fridge, lights, kettle, projector or many portable tools. Because the petrol engine can recharge the battery, a plug-in hybrid makes a particularly practical power source on a worksite or campsite.
V2L Vehicle to Load
DC fast charging (CCS2): unusual on a plug-in hybrid and genuinely useful. The Tiggo 7 and 8 accept up to 40kW and the Tiggo 9 up to 71kW, both taking 30–80% in around 20 minutes. Charging slows sharply above 80%, so on a road trip a short stop to 80% and back on the road beats waiting for a full battery. DC chargers have cables attached.
Public AC charging (Type 2): at supermarkets, malls, hotels and motels you’ll usually need your own Type 2 cable. For charger locations, networks and apps, see our full New Zealand public charging guide, or check PlugShare before you travel.
A Type 2 inlet for AC charging and CCS2 for DC fast charging, on the Tiggo 7, 8 and 9 alike. Untethered and public AC chargers require a Type 2-to-Type 2 cable.
A 7.4kW (32A) single-phase smart wall charger. It supplies more than the car’s 6.6kW limit, so every Tiggo CSH charges as fast as it can — about 2.8 hours for the Tiggo 7 and 8, or 5.2 hours for the Tiggo 9.
No, and there is no benefit in buying one for these cars. The onboard charger is limited to 6.6kW, so a 22kW three-phase charger charges no faster than a 7.4kW single-phase unit. Three-phase is only worth it if you also charge a vehicle that can use it.
The Tiggo 7 and 8 share an 18.4kWh battery with around 90km of electric range and DC charging to 40kW. The Tiggo 9 has a 34.46kWh battery, roughly 146km of electric range and DC charging to 71kW. All three charge on AC at the same 6.6kW.
Yes. A 10A portable Type 2 charger fills a Tiggo 7 or 8 from a standard household socket in around 8 hours — a single overnight charge. The Tiggo 9’s larger battery takes about 15 hours, so a wall charger is the better option there.
One with a Type 2 vehicle connector and a mains plug suitable for your socket. A 10A model uses a standard NZ socket; a 16A model uses a dedicated blue caravan-style socket and charges faster. See our portable chargers above.
A Type 2 to Type 2 cable in 5m. A single-phase cable carries everything these cars can take; a 22kW three-phase cable is optional future-proofing for a later vehicle.
No — it drives as a hybrid on petrol alone. But the advertised fuel figures assume a charged battery, and with 90km (Tiggo 7 and 8) or around 146km (Tiggo 9) of electric range, most NZ daily driving can be done without petrol if you charge at home. That’s where a wall charger pays for itself.
The Tiggo 7 and 8 use an LFP battery, which is generally more tolerant of regular 100% charging than many nickel-based EV batteries. Follow the charging guidance in your vehicle manual for your specific model.
Up to 40kW on the Tiggo 7 and 8, and up to 71kW on the Tiggo 9, via CCS2 — roughly 30–80% in 20 minutes on either. Charging slows considerably above 80%.
Yes — up to 3.3kW through a plug-in adapter that provides a standard NZ socket, enough for appliances such as a fridge, lights, kettle or portable tools. We sell the compatible adapter here.
It depends on the distance from your switchboard to the parking spot, how straightforward the cabling run is, and your existing switchboard capacity. We can arrange installation quotes through our installer network, available in many locations nationwide, or you can buy the charger only and use your own electrician. Request a quote here.
