BYD Sealion 8 PHEV Home Chargers, Cable & Charging Guide NZ

Get the most from your BYD Sealion 8 by charging at home instead of relying mainly on petrol. A 7.4kW single-phase wall charger is the ideal choice for every Sealion 8 variant, delivering the car’s maximum home charging speed with convenient overnight charging, app scheduling and optional solar integration.

Below, you can compare chargers, charging times, cables, portable charging, public charging and V2L options for the BYD Sealion 8 in New Zealand.

Shop Sealion 8 home chargers Shop portable chargers Shop charging cables Shop V2L adapter
byd sealion 8 home charging

Best wall charger

7.4kW / 32A single-phase

Car draws up to 7kW

Home charge time

Dynamic FWD ~2.7 hrs
AWD models ~5.1 hrs

10–100% at 7kW

Public AC cable

Type 2 to Type 2, 5m

For public AC and socket-only wall chargers

DC fast & V2L

40kW (FWD) • 74kW (AWD)

CCS2 • V2L supported — adapter here

Charging factDynamic FWD (DM-i)Dynamic & Premium AWD (DM-p)
AC connectionType 2
Maximum AC rate7kW single-phase
Battery19kWh Blade (LFP)35.6kWh Blade (LFP)
Best option for most homes7.4kW single-phase wall charger
Public DC connectionCCS2 — up to 40kWCCS2 — up to 74kW
V2LYes — adapter required

Best home wall charger for the BYD Sealion 8

Best for every Sealion 8

7.4kW smart wall chargers

A single-phase 7.4kW (32A) charger covers the car’s full 7kW AC rate: about 2.7 hours for the Dynamic FWD, or 5.1 hours for the AWD models’ larger battery. Giving you a full charge overnight.

Buy the tethered version if: you want the simplest everyday option — pull in, plug in, done.
Buy the socket (untethered) version if: you want a tidier wall unit, already own a Type 2 cable, or share the charger between vehicles.

Load monitoring prevents overloading your mains while charging. Solar diversion varies charging power to match your solar generation — well suited to a PHEV, since a modest array can cover most of a charge during the day. Scheduling via the free app makes the most of off-peak rates.

sealion 8 public charging

BYD Sealion 8 charging cost & time calculator

Pick your variant — it sets the battery size automatically. All Sealion 8 models accept a maximum of 7kW AC.

Estimated time to charge

To 100% from your start %

Estimated cost to charge

$0.00
0.00 kWh from the wall (approx)
byd sealion 8 home charging

About the BYD Sealion 8

Three variants, two batteries

The Sealion 8 is BYD’s large seven-seat plug-in hybrid, built on the DM 5.0 powertrain with an LFP Blade Battery. The Dynamic FWD uses a 19kWh pack for up to 103km of electric range; the Dynamic AWD and Premium AWD step up to 35.6kWh and 152km, with 359kW and a 4.9-second 0–100km/h.

All three charge the same way on AC: Type 2 at 7kW maximum. What changes is how long a full charge takes and how fast each accepts DC on the road. Range figures are NEDC — expect roughly 80km (FWD) and 120km (AWD) in real-world NZ driving.

Official BYD Sealion 8 page →

ItemDynamic FWDDynamic AWD / Premium AWD
Battery size19kWh Blade (LFP)35.6kWh Blade (LFP)
Electric-only rangeUp to 103km (NEDC)Up to 152km (NEDC)
Combined rangeUp to 1118kmUp to 1017km
Output205kW / 315Nm359kW / 675Nm
AC charge portType 2
Maximum AC charge speed7kW single-phase
DC charge portCCS2
Maximum DC charge speedUp to 40kWUp to 74kW
V2LYes — adapter required

BYD Sealion 8 home charging times

Charge times from 10% to 100%. The last few percent slow down as the cells balance, so these are estimates.

Charger typeCharging powerDynamic FWD (19kWh)AWD models (35.6kWh)
Portable charger, standard NZ socket (8A)1.8kW~10.3 hrs~19.3 hrs
10A portable Type 2 charger2.3kW~8.3 hrs~15.5 hrs
16A portable charger (caravan plug)3.7kW~5.2 hrs~9.7 hrs
32A single-phase wall charger7kW (vehicle limit)~2.7 hrs~5.1 hrs

Estimates allow for approximately 10% charging losses. Actual speed can vary with temperature, battery condition and the vehicle’s charging behaviour near 100%.

How much electric range will each charger add?

Kilometres of electric driving added per hour of charging, based on NEDC range — expect real-world figures around 20–25% lower. On a plug-in hybrid this is the number that matters most: every kilometre you add is a kilometre you don’t buy petrol for.

ChargerDynamic FWDAWD models
8A portable charger (standard socket)~9km per hour~7km per hour
10A portable charger~11km per hour~9km per hour
16A portable charger (caravan socket)~18km per hour~14km per hour
7.4kW wall charger (7kW to the car)~34km per hour~27km per hour

Want exact numbers for your power price and starting charge? Use the calculator below, or see our charge time calculator and charge cost calculator.

Portable charger for the BYD Sealion 8

A portable Type 2 charger plugged into a standard household socket fills the Dynamic FWD in around 8.3 hours on 10A — a single overnight charge. The AWD models’ 35.6kWh battery takes about 15.5 hours, so a wall charger is the practical choice there. A 16A model on a correctly installed blue caravan-style socket roughly halves both.

Buy the 10A if: you want a travel charger for the bach and family visits, or a faster replacement for the unit supplied with the car.
Buy the 16A if: you have (or will install) a dedicated caravan-style socket and want the fastest portable option.

Any portable charger for the Sealion 8 must have a Type 2 vehicle connector.

10a Smart EV Charger Type 2

Plug in EV chargers

10a Plugin EV Charger Type 2

$399.00 inc. GST
16a type 2 ev charger

Plug in EV chargers

Portable 16A EV Charger – Blue Caravan Plug

$415.00 inc. GST

What charging cable does the Sealion 8 need?

Vehicle-side plug: Type 2. You’ll need your own Type 2 to Type 2 cable for public AC chargers, and for any untethered (socket-only) wall charger — including the basic charger BYD supply with the car if yours has a socket rather than a fixed cable. We recommend 5m.

Because the car caps at 7kW, a single-phase 7kW cable is sufficient. A 22kW three-phase cable also works and is worth considering only if you may later own a car that charges faster.

Most free public AC chargers use a Type 2 socket and need your own cable; some have one hard-wired. DC fast chargers always have their cables attached.

Type 2 to Type 2 ev charging cable

Charging Cables

Type 2 to Type 2 charge cable 32a 7kW

Price range: $175.00 through $355.00 inc. GST
type2 to type 2 charger cable

Charging Cables

Type 2 to Type 2 EV Charge Cable 22kW 3 Phase

Price range: $225.00 through $279.00 inc. GST

Power anywhere

BYD Sealion 8 V2L adapter

The Sealion 8 supports Vehicle-to-Load through an adapter that plugs into the charge port and gives you a standard New Zealand socket — enough for a fridge, lights, kettle, projector or many portable tools. BYD supply an adapter with the car; we stock spares if you want a second one, or a replacement.

Because the petrol engine can recharge the battery, a plug-in hybrid makes a particularly practical power source on a worksite, at a campsite or in an outage. V2L powers appliances plugged into the adapter — it is not a connection to your home’s fixed wiring and cannot backfeed your switchboard.

Vehicle to Load cable V2L for Smart #1 or #3

V2L Adapter for BYD

$165.00 inc. GST

Public charging with the BYD Sealion 8

DC fast charging (CCS2): useful and unusual on a plug-in hybrid. The Dynamic FWD accepts up to 40kW and the AWD models up to 74kW. Charging slows sharply above 80%, so on a road trip a short stop to 80% and back on the road beats waiting for a full battery. DC chargers have cables attached. The main NZ networks are ChargeNet, BP Pulse, Z and Tesla — all covered in our public charging guide.

Public AC charging (Type 2): at supermarkets, malls, hotels and motels you’ll usually need your own Type 2 cable. Check PlugShare for chargers in your area and what cables they need.

BYD Sealion 8 charging FAQs

What type of charger does the BYD Sealion 8 use?

A Type 2 inlet for AC charging and CCS2 for DC fast charging, across all three variants. Untethered and public AC chargers require a Type 2-to-Type 2 cable.

A 7.4kW (32A) single-phase smart wall charger. It covers the car’s full 7kW AC rate, charging the Dynamic FWD in about 2.7 hours and the AWD models in about 5.1 hours from 10–100%.

No, and there is no benefit in buying one for this car. The onboard charger is limited to 7kW, so a 22kW three-phase charger charges no faster than a 7.4kW single-phase unit. Three-phase is only worth it if you also charge a vehicle that can use it.

The Dynamic FWD has a 19kWh Blade Battery, up to 103km of electric range and DC charging to 40kW. The Dynamic AWD and Premium AWD have a 35.6kWh pack, up to 152km and DC charging to 74kW. All three charge on AC at the same 7kW, so the AWD models simply take about twice as long at home.

It will charge the car, but slowly — a portable charger on a standard socket takes around 10 hours for the Dynamic FWD and over 19 for the AWD models. A wall charger cuts that to a few hours and adds scheduling, load monitoring and solar diversion, which the supplied unit doesn’t have.

Yes. A 10A portable Type 2 charger fills the Dynamic FWD in around 8.3 hours — a single overnight charge. The AWD models take about 15.5 hours, so a wall charger is the better option there.

A 7kW Type 2 to Type 2 cable in 5m. That carries everything the car can take on AC, and it’s also the cable you need between the car and a socket-only wall charger.

No — it drives as a hybrid on petrol alone, with over 1000km of combined range. But the advertised fuel figures assume a charged battery, and with around 80–120km of real-world electric range, most NZ daily driving can be done without petrol if you charge at home.

Yes. The Blade Battery uses LFP chemistry, which is designed for regular full charging — unlike many nickel-based EV batteries. BYD in fact recommend periodically charging to 100% to keep the battery gauge accurate. Follow the guidance in your vehicle manual.

Up to 40kW on the Dynamic FWD and up to 74kW on the AWD models, via CCS2. Charging slows considerably above 80%.

Yes — through a plug-in adapter that provides a standard NZ socket, enough for appliances such as a fridge, lights, kettle or portable tools. BYD supply one with the car; we stock spares and replacements.

It depends on the distance from your switchboard to the parking spot, how straightforward the cabling run is, and your existing switchboard capacity. We can arrange installation quotes through our installer network, available in many locations nationwide, or you can buy the charger only and use your own electrician. Request a quote here.
