Arcfox T1 Home Charger (NZ): Best Wall Chargers, Cables & Charging Times

Looking for the right Arcfox T1 home wall charger? This guide covers everything: which EV wall charger to install at home, how fast the T1 charges, and what cable you need for public AC chargers.

The Arcfox T1 is a compact electric crossover launching in New Zealand from July 2026, with 310km of WLTP range. The T1 is powered by a 42.3kWh LFP battery and supports AC home charging at up to 7kW (single-phase) — a perfect match for a standard NZ home wall charger, no special wiring required. DC fast charging is rated at 30–80% in around 17 minutes on a compatible rapid charger (figures based on overseas-market specification; NZ-confirmed DC rate pending).

Official Arcfox T1 NZ Page

Arcfox T1 Specification Value
Battery (capacity) 42.3kWh (LFP) — overseas-spec figure, NZ TBC
Range 310km (WLTP) — NZ confirmed
Motor / Drive 70kW or 95kW — front-wheel drive
Warranty 6 years / 200,000km
Max AC charging (home) 7kW (single-phase)
Max DC fast charging Not yet confirmed for NZ
Typical DC session 30–80% in ~17 minutes (overseas-spec figure, conditions apply)
Typical full AC charge (7kW) ~6 hours (10–100%, estimated)



Best Home Wall Chargers for the Arcfox T1

Fast, reliable overnight charging — and future-proof for your next EV

The Arcfox T1’s onboard AC charger is rated at up to 7kW on a standard single-phase connection — which is exactly what a typical NZ home has. A standard 7kW / 32A wall charger is the ideal home setup. A full home charge takes around 6 hours from 10% to 100%, so an overnight plug-in will be ready well before morning.

Choose your home charging style:
• Tethered wall charger (fixed cable): the easiest daily experience — plug in and go
• Untethered wall charger (socket only): use your own Type 2 cable — great if you share a charger between vehicles or want one cable for home and public AC charging
• Solar-aware charger: if you have solar, a smart charger that diverts excess solar means you can charge the T1 for free during the day

32a Smart EV charger with attached Type 2 cable and wifi

Smart EV Wall charger with DLB includes 6m cable & WIFI

$780.00 inc. GST
32a 22kW wall charger type 2 socket with wifi

Smart EV Wall charger with DLB and WIFI 7.4kW

Price range: $689.00 through $850.00 inc. GST
Type 2 to Type 2 ev charging cable

Type 2 to Type 2 charge cable 32a 7kW

Price range: $175.00 through $355.00 inc. GST

Arcfox T1 charge times (home) — quick guide

Estimates below assume charging from 10% to 100% with typical wall-to-battery efficiency, based on a 42.3kWh battery (overseas-spec figure, NZ TBC). The T1’s onboard AC charger caps at 7kW (single-phase).

Home charging setup Approx. power Est. time (10% → 100%)
Included (8A) / standard socket ~1.8kW ~21 hours
Portable charger (10A) ~2.3kW ~17 hours
16A charger (caravan/commando style) ~3.7kW ~10 hours
7kW wall charger (32A, full onboard rate) 7kW ~5.5 hours

Want exact numbers for your power price and start %? Use the calculator on the right.

arcfox t1 home charging
Arcfox T1 public charging

Arcfox T1 Charging Cost & Time Calculator

Battery figure (42.3kWh) is based on the equivalent overseas-market model • NZ-confirmed figure pending

Estimated time to charge

To 100% from your start %

Estimated cost to charge

$0.00
0.00 kWh from the wall (approx)

Public charging with the Arcfox T1 (NZ)

DC fast charging
The T1 can DC fast charge with a quoted 30–80% session in approximately 17 minutes on a compatible rapid charger (conditions apply, NZ figures TBC). That would make it a quick top-up on a longer trip. DC chargers have cables attached so there is no need to bring a cable for these.

Type 2 AC chargers
AC public chargers are slower, making them ideal when you’re parked in one spot for a while — at a mall, hotel, gym or workplace. Some have a Type 2 cable already attached, while others are “bring-your-own-cable” and need your own Type 2 to Type 2 cable. PlugShare is handy for checking what’s available at your destination before you leave.

Popular Apps for Fast charging

Provider Notes Apple App Android App
ChargeNet Largest network nationwide Download Download
BP Fast chargers at key sites Download Download
Z Energy Fast chargers at selected stations Download Download
Tesla Most NZ Superchargers are open to non-Tesla Download Download

What cable do I need for public AC charging?

We recommend a Type 2 to Type 2 cable (7kW-rated)
A 5m length suits most public AC bays and parking layouts.

Does it support V2L.

The oversease model does so we suspect that the New Zealand model will. When they land here we will test our V2L cables to check compitability.

Arcfox T1 home charging FAQs (NZ)

What is the best home wall charger for the Arcfox T1?

A 7kW (32A) wall charger is the ideal home setup for the T1. The T1’s onboard AC charger is rated at up to 7kW single-phase (based on the equivalent overseas-market model), so a standard 32A wallbox delivers the T1’s full home charging speed — a full charge in around 6 hours, with no special wiring required.

No. The T1 charges at up to 7kW on a standard single-phase connection, which is what almost all NZ homes have. A standard 32A single-phase wall charger is all you need.

Arcfox New Zealand has confirmed the T1 offers 310km of WLTP range. Real-world range will vary with driving style, terrain and conditions, but it’s well suited to daily commuting and city driving.

Yes — however a full 10–100% charge takes around 21 hours (based on the estimated battery size), so a standard socket is best as an occasional backup rather than your main charging method. A 7kW wall charger is strongly recommended for daily use.

A Type 2 to Type 2 cable is the right choice for NZ AC destination charging. We suggest a 7kW-rated cable in 5m.

Based on the equivalent overseas-market model, yes — the T1 is expected to charge from 30–80% in approximately 17 minutes on a compatible DC rapid charger (conditions apply). Official NZ DC charging specifications haven’t yet been confirmed by Arcfox; we’ll update this page once they are.

Expert Arcfox T1 charging advice

Want the easiest, safest charging setup at home? We’ll help you choose the right wall charger, cable length,
and installation approach for your driveway or garage — including solar-ready options.

Free advice includes:
– Charger recommendation (best value 7kW unit for the T1)
– Installation quote (nationwide options)
– Solar-aware charger options (divert excess solar to charge for free)
– Public charging cable advice
– Smart load management for shared-supply homes
